Thermoplastics - Semi Finished Plastic Sheets

Generic Name: POM / Acetal / Delrin/formaldehyde

Brand name: Sustarin® C

Material Description: Semi crystalline with High dimensional stability

Properties:

• Good UV resistance
• High Dimensional accuracy
• low moisture absorption
• Good sliding behaviour
• Good electric and dielectric properties

Chemical Resistance:

• Resistant to Hydrocarbons, alkalis, greases, oils, fuels, ethers, esters, ketones, water up to 100 deg C
• Not Resistant to halogens, acids, oxidizing agents, nitrogen oxides

Applications  :

• Mechanical Engineering, Automotive Industry, Textile Industry

• Food Processing Industry - Cams, Sprockets, guides, star wheels, bushes, holders, Gears, wear plates, guide rollers, feed worms

• Machine building - mainfolds, bushes, Gears,Snap on connections, flangers

• Medical & Pharma - Surgical Handles, Sterlisation boxes, trays, billets seperators, pick and place parts

Sizes :

Calendered Sheets : 1 mm to 10 mm thickness, Size : 1000 x 2000 mm

Standard Sheets     : 10 mm to 150 mm, Size: 3000 x 620 mm & 1000 x 2000 mm

Rods                       : Ø 5 mm to Ø 400 mm , L 1000 mm / L 3000 mm

Various POM /Delrin Grades available for Food Grade, Medical Grade, Electrical Grade & for Antistatic Propertires.

Generic Name: POM / Acetal / Delrin/formaldehyde

Brand name: Sustarin® C

Material Description: Semi crystalline with High dimensional stability

Properties:

• Good UV resistance
• High Dimensional accuracy
• low moisture absorption
• Good sliding behaviour
• Good electric and dielectric properties

Chemical Resistance:

• Resistant to Hydrocarbons, alkalis, greases, oils, fuels, ethers, esters, ketones, water up to 100 deg C
• Not Resistant to halogens, acids, oxidizing agents, nitrogen oxides

Applications  :

• Mechanical Engineering, Automotive Industry, Textile Industry

• Food Processing Industry - Cams, Sprockets, guides, star wheels, bushes, holders, Gears, wear plates, guide rollers, feed worms

• Machine building - mainfolds, bushes, Gears,Snap on connections, flangers

• Medical & Pharma - Surgical Handles, Sterlisation boxes, trays, billets seperators, pick and place parts

Sizes :

 Calendered Sheets : 1 mm to 10 mm thickness, Size : 1000 x 2000 mm

Standard Sheets     : 10 mm to 150 mm, Size: 3000 x 620 mm & 1000 x 2000 mm

Rods                       : Ø 5 mm to Ø 400 mm , L 1000 mm / L 3000 mm

Various POM /Delrin Grades available for Food Grade, Medical Grade, Electrical Grade & for Antistatic Propertires.

Semi-Crystalline thermoplastics

Generic Name : PA6 (EXTRUDED NYLON), PA6G(Cast Nylon)

Brand Name    : Sustamid 6®/ Sustamid 6G®

Special properties

• Good toughness
• Very good noise and vibration absorption
• Very good sliding properties
• high absorption of moisture of up to 3 % in standard atmosphere
• High abrasion resistance
• high mechanical strength coupled with high impact strength
• excellent machinability
• good adhesive properties
• good weldability

Chemical Resistance : Resistant to Hydrocarbon , alkalies , Grease , oil , fuels , ketones , ether

                                         Non resistant to halogens, mineral acids & certain organic acids, oxidising agents

Application :

• Mechanical engineering
• Aircraft construction
• Food processing industry
• Offshore
• Vehicle construction

Standard Sizes :

Sheets : 6 mm to 150 mm in 2500 x 1250 mm  & 2000 x 1000 mm

Rods : 50 mm to 610 mm Dia in 1000 mm / 3000 m Length

Colours : Ivory White , Black , Yellow , Blue , Green

Variants /Grades: Sustamid® 6 FG, Sustamid® 6 MO, Sustamid® 6 GC, Sustamid® 6 GC MO, Sustamid® 6 GF 30,            Sustamid® 6 ESD 60,Sustamid® 6 FR,Sustamid® 6 GF, Sustamid® 6G, Sustamid® 6G MO, Sustamid® 6G HS, Sustamid® 6G ESD 60, Sustamid® 6G ESD 90, Sustamid® 6G OL

Generic Name       : PolyEtherEtherKeton (PEEK)

Brand Name             : SustaPEEK®

Material Description : High performance plastic with high operating temperature range, chemical resistance, and dimensional stability  , Semi - Crystalline thermoplastic

Sizes:
Sheets : 1 to 100 mm, 1m x 2m, 1m x 620 mm
Rods : 5 to 200 mm Dia L 1m & 3m

Properties:

• excellent dimensional stability
• hardly inflammable and self-extinguishing=
• extremely low smoke density
• very high resistance to high-energy radiation
• outstanding sliding properties
• excellent abrasion resistance
• high wear resistance
• optimised balance of stiffness, tensile strength and impact strength
• low creep tendency
• good machinability,thermoformability & weldability
• good adhesive properties
• high dimensional stability under heat
• extremely high continuous service temperature
• low coefficient of linear thermal expansion

Applications : Medical Engineering, Aviation Industry, Electric Industry

Colours : Natural & Black

Grades/Variants :

• SustaPEEK® MG (Medical Grade)
• SustaPEEK® MOD   (Carbon, PTFE, and Graphite filled)
• SustaPEEK® CF 30 (Carbon filled)
• SustaPEEK® GF 30 (Glass filled)

Generic Name: Polyethylene Terephthalate

Brand Name: Sustadur® PET

Material Description: High-grade and high-strength technical parts

Size : 8 to 100 mm in 3000 x 620 mtr & 2 to 12 mm in 2000 x 1000 mtr (Sheet)

Properties:

• Excellent dimensional stability (better than all the polyamides and polyacetals)

• Extremely low moisture absorption Good sliding properties

• Excellent creep behaviourGood sliding propertiesGood wear resistance

• Extremely high tensile strength and hardness

• Extremely high stiffness

• Good machinability, Good adhesive property, Good weldability



• Extremely low thermal expansion

• Good electrical insulating properties

Chemical Resistance: hydrocarbons, greases, oils, fuels, ethers, esters, ketones, Water up to approx. 40°C, acids (diluted)

Applications:

• Ship building Industry
• Material Handling Industry
• Food Processing Industry
• General Mechanical & Plant Engineering
• Electronic Industry
• CAM'S Scroll/Worms in food processing equipments

Generic Name: POM / Acetal / Delrin/formaldehyde

Brand name: Sustarin® C

Material Description: Semi crystalline with High dimensional stability

Properties:

• Good UV resistance
• High Dimensional accuracy
• low moisture absorption
• Good sliding behaviour
• Good electric and dielectric properties

Chemical Resistance:

• Resistant to Hydrocarbons, alkalis, greases, oils, fuels, ethers, esters, ketones, water up to 100 deg C
• Not Resistant to halogens, acids, oxidizing agents, nitrogen oxides

Applications  :

• Mechanical Engineering, Automotive Industry, Textile Industry

• Food Processing Industry - Cams, Sprockets, guides, star wheels, bushes, holders, Gears, wear plates, guide rollers, feed worms

• Machine building - mainfolds, bushes, Gears,Snap on connections, flangers

• Medical & Pharma - Surgical Handles, Sterlisation boxes, trays, billets seperators, pick and place parts

Sizes :

Calendered Sheets : 1 mm to 10 mm thickness, Size : 1000 x 2000 mm

Standard Sheets     : 10 mm to 150 mm, Size: 3000 x 620 mm & 1000 x 2000 mm

Rods                       : Ø 5 mm to Ø 400 mm , L 1000 mm / L 3000 mm

Various POM /Delrin Grades available for Food Grade, Medical Grade, Electrical Grade & for Antistatic Propertires.

Generic Name             : Polypropylene PP

Brand Name            : Polystone® P

Material Description : Isotactic, highly heat stable PP available as Homopolymer, and Copolymer

Properties :

• High Chemical and Corrosion Resistance
• Excellent Weldability
• Greater rigidity and strength

Chemical Resistance:

• Highly Resistant to acids, alkalis, alcohols, aldehyde organic solvents, grease
• Limited Resistance or swelling to some hydrocarbons (eg Fuels)
• Not Resistant to oxidising agents

Applications :

• Storage Tanks for Corrosive Chemcials
• Plating Tanks
• Pickling Tanks
• Tanks for Water treatment plants
• Scrubbers
• Fume Ductings

Standard Sizes :

Sheets : 5 mm to 30 mm in 3000 x 1500 mm & 4000 x 2000 mm

Rods   : 6 mm to 300 mm Ø in 3000 mm L/ 1000 mm L

Colours : Grey, Natural, White

Variants/Grades:

• Polystone® P White Micro AST (anti-static)
• Polystone® P Copolymer (low temp application, suitable upto -30 deg c)
• Polystone® P Homopolymer (high mechanical strength, High chemical and corrosion resistance)
• Polystone® P MG (medical grade)
• Polystone® P SK/GK (fabric backed /glass fabric backed)
• Polystone® P SSAG (High Temp)
• Polystone® PP TV (vaccum forming)
• Polystone® PPs EL black (Flame retardant and electrically conductive)
• Polystone® PPs grey (Flame retardant)

Polystone® PVDF is a vinylidene-fluoride-based polymerisate outstanding for its excellent chemical resistance, excellent machinability and universal applicability. Because of its special properties Polystone® PVDF is especially suited for applications in the chemical industry. Its high purity makes it the ideal material for the semiconductor industry.

Polystone® PVDF meets the requirements of the FM-Test 4910 (Factory Mutual Research Specification Test) and is thus an approved material for use in semiconductor and clean room technology.

Generic name: Polyvinylidene fluoride PVDF

Brand Name: Polystone® PVDF

Material Description: Semi-crystalline thermoplastic that belongs to the group of fluorine polymers

Properties:

• High mechanical strength, and stiffness
• Outstanding resistance to acids
• Flame retardant
• Excellent Weldability

Chemical resistance:
Highly resistance acids, oxidizing acids, halogens, alcohols, chlorinated solvents

Application Area:

• Inliners for Chemical storage tanks
• Semi conductor Industry
• Clean room Industry
• Inliners in Chrome plating plants
• Pump Casings and Impellers

Variants (Grades):

• Polystone® PVDF
• Polystone® PVDF SK/GK (fabric backed /glass fabric backed

Type of Product:

• coils
• compression moulded sheets
• extruded sheets
• round rods
• square tubes
• U Profiles
• Weding Rods

Brand : Polystone® M

Colour : Black, Red, Natural, Green, Blue

Material : UHMWPE

Product Type : compression moulded sheets, pressed sheets, round rods, skived sheets

Density : 0.93

Thickness : 1 mm to 6 mm, 8 mm to 80 mm Sheets in 3000 x 1250 mm, Rods 8mm to 260mm Dia in 3 mtr & 1 mtr length

Generic name : UHMWPE (Ultra-high-molecular-weight polyethylene)/PE 1000

Application: Beverage & Food Industry, Mechanical Engineering, Packaging Industry, Material Handling, Dock Fenders

Special Properties:

• High Abrasion and Wear Resistances
• Low coefficient of friction
• High Impact strength
• Self-lubricating properties
• No water absorption
• Excellent performance even at  -200 °C
• High resistance to corrosion and chemicals
• Excellent resistance to stress cracks
• Operating temperature range  -250°C to 80°C
• Short term max temperature  130°C

Special Grade:  Polystone® M Black AST  (anti-static), Polystone® M Black EL (electrically conductive), Polystone® M Slide, Polystone® M Saphir, Polystone® M Polyblue,Polystone® M Flametech,Polystone® M EHS,Polystone® M Microbloc,Polystone® MPG (Glass-filled, for paper machinery)
